Name: Electric Pneumatic Forklift
Brand: Toyota

Overview

Need a powerful, outdoor solution but want to maintain an electric fleet? The Toyota Electric Pneumatic Forklift is a truck you count on. Get the benefits of electric without compromising IC performance. Stacked with an

3-Way hydraulic control valve

System of Active Stability (SAS) automatically detects unsafe conditions and engages additional safety features for increased operator protection and reduced product and forklift damage.

Twice the run time of it’s 36v or 48v competitors

Excellent visibility

Rust proof model - Offers extra protection on components that are prone to rust when exposed to moisture or corrosive elements such as salt, water or brine

Over 65 options and countless configurations to build the perfect forklift for your application

T-Matics Vehicle Management System - tracks impacts, utilization and maintenance schedules

Cascade Integral Side-Shifting Fork Positioner W/A450 - provides an integral side shifting fork positioner with the side shifter as the 3rd function and the fork positioner as the 4th function

Better performance. More versatility.

4,000 +6

Load Capacity (lbs)

11.8 / 11

Max. Travel Speed Full Load (MPH)

96 / 91 / 75 / 69 / 68.9 / 65

Max. Lift Speed Full Load (FPM)

Model Specifications

Compare model specifications for this equipment family.
Model Number	Load Capacity (lbs)	Max. Travel Speed Full Load (MPH)	Max. Lift Speed Full Load (FPM)	Max. Gradeability Full Load (%)	Basic Right Angle Stack (In.)
05-8FBM20T	4,000	11.8	96	26	95.4
05-8FBM25T	5,000	11.8	91	24	100.7
05-8FBMK25T	5,000	11.8	91	25	95.4
05-8FBM30T	6,000	11.8	75	22	101.5
05-8FBMK30T	6,000	11.8	75	21	97.3
05-8FBM35T	7,000	11.8	69	19	102.6
8FBM40T	8,000	11	68.9	15	120.5
8FBM45T	9,000	11	68.9	14	121.1
8FBM50T	11,000	11	65	13	126.5

05-8FBM20T

Load Capacity (lbs): 4,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 96
Max. Gradeability Full Load (%): 26
Basic Right Angle Stack (In.): 95.4

05-8FBM25T

Load Capacity (lbs): 5,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 91
Max. Gradeability Full Load (%): 24
Basic Right Angle Stack (In.): 100.7

05-8FBMK25T

Load Capacity (lbs): 5,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 91
Max. Gradeability Full Load (%): 25
Basic Right Angle Stack (In.): 95.4

05-8FBM30T

Load Capacity (lbs): 6,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 75
Max. Gradeability Full Load (%): 22
Basic Right Angle Stack (In.): 101.5

05-8FBMK30T

Load Capacity (lbs): 6,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 75
Max. Gradeability Full Load (%): 21
Basic Right Angle Stack (In.): 97.3

05-8FBM35T

Load Capacity (lbs): 7,000
Max. Travel Speed Full Load (MPH): 11.8
Max. Lift Speed Full Load (FPM): 69
Max. Gradeability Full Load (%): 19
Basic Right Angle Stack (In.): 102.6

8FBM40T

Load Capacity (lbs): 8,000
Max. Travel Speed Full Load (MPH): 11
Max. Lift Speed Full Load (FPM): 68.9
Max. Gradeability Full Load (%): 15
Basic Right Angle Stack (In.): 120.5

8FBM45T

Load Capacity (lbs): 9,000
Max. Travel Speed Full Load (MPH): 11
Max. Lift Speed Full Load (FPM): 68.9
Max. Gradeability Full Load (%): 14
Basic Right Angle Stack (In.): 121.1

8FBM50T

Load Capacity (lbs): 11,000
Max. Travel Speed Full Load (MPH): 11
Max. Lift Speed Full Load (FPM): 65
Max. Gradeability Full Load (%): 13
Basic Right Angle Stack (In.): 126.5

Ready for anything

Moving Materials Efficiently

Improve productivity by safely transporting materials, pallets, and inventory throughout your facility with equipment designed to keep operations moving.

Warehouse & Distribution Operations

Support receiving, storage, picking, and shipping activities with equipment built to maximize throughput and optimize available warehouse space.

Manufacturing & Production Support

Keep production lines supplied and workflows uninterrupted with dependable material handling solutions designed for demanding industrial environments.

Indoor & Outdoor Applications

Operate confidently across a variety of environments, from warehouse aisles and loading docks to outdoor yards and job sites, depending on your application needs.
